DHT531 is a LED driver IC for the high-speed digital audio communication using a plastic optical fiber(POF).
- Feature
- Input TTL interface compatible
- High speed operation (50Mbps)
- Wide supply voltage range (2.7V ~ 5.5V)
- Constant current output (3mA)
- Low quiescent current (280uA)
- Chip Photo
- Reliability
- HBM CLASS 3B (>8000V) - JS-001-2012
- MM CLASS C (>400V) - JESD22-A115C:2010
- CDM CLASS IV (>1000V) - JESD22-C101E:2009
- Applications
- Digital TV
- DVD Player
- Set-Top Box
- Game Consoles
- S/PDIF applications with TOSLINK
- Package & Housing Example for application
- Application Examples
- Application Connection Examples
